NovaStar TU20 Pro Playback Control Processor
The NovaStar TU20 Pro is an all-in-one Android playback controller for indoor LED displays, combining Android playback with LED sending, wireless mirroring, presentation and remote meeting support.
Key Features
- Android playback and LED sending in one device
- Wireless mirroring from Windows, macOS, iOS and Android
- 1080p mirroring up to 60 fps
- Latency ≤80 ms within 8 m
- Four display modes for varied applications
- 6 Ethernet outputs for TU20 Pro
Technical Specifications
| Model | Parameter | Specification |
|---|---|---|
| Electrical Specifications | Input voltage | DC 12V 3A, Negative Outside Positive Inside (power adapter input) |
| Rated power consumption | 21 W | |
| Storage Space | RAM | 4 GB |
| Internal storage | 32 GB | |
| Operating Environment | Temperature | −20°C to +50°C |
| Humidity | 0% RH to 80% RH, non-condensing | |
| Storage Environment | Temperature | −30°C to +80°C |
| Humidity | 0% RH to 95% RH, non-condensing | |
| Physical Specifications | Dimensions | 211.7 mm × 185.0 mm × 50.6 mm |
| Net weight | 1.12 kg | |
| Gross weight | 2.9 kg · Note: It is the total weight of the product, accessories, and packing materials packed according to the packing specifications. |
